Modular Conveyors

ModQuip modular conveyors are designed for fast, practical, and cost-effective installation. Assembled from locally stocked components, they are available for immediate delivery and can be manufactured and put together using basic tools – no welding or specialised equipment required. To further reduce costs, each conveyor is flat-packed for efficient transport, allowing quick delivery anywhere across Australasia. For projects requiring extra support, we also provide full assembly, on-site installation and commissioning.

Conveyors can be ordered in a range of standard widths and lengths, or tailored to meet specific requirements. With our responsive design process, custom layouts can be developed in just hours, ensuring your system is ready to perform without unnecessary delays.

Features

Conveyor widths also available in 1250mm and 1400mm
All Conveyors are powder coated before assembly
Inclination up to 33 degrees available
Stainless Steel Conveyors available for food application and corrosive environments
Standard Duty and Heavy Duty trough conveyor also available
All Speeds available – All Drives supplied from Inquip stock
VSD Drives – Scrapers – Magnets – Diverter Chutes and many other standard additions available

Conveyor Lengths available in 500mm increments
Special customised designs available
3D Models available
Conveyors supplied flat packed for on-site assembly and economical installation
Site installation teams available in all states
Designed and manufactured in Australia
Distributors, Service Agents and Parts available throughout Australia.

Product Specifications

Standard sizes (width)

400mm
600mm
900mm
1200mm

Code	Standard Widths	TPH	Angle	Head Drum DIA	RPM	Standard Speed Mtr/Sec	Standard Conveyor Length (Available up to 100 metres)
Code	Standard Widths	TPH	Angle	Head Drum DIA	RPM	Standard Speed Mtr/Sec	3m	5m	8m	10m	15m	20m
MQPA050A	300	5	0	168	56.8	0.5	0.37 kW	0.37 kW	0.37 kW	0.37 kW	0.37 kW	0.37 kW
MQPA050A	300	5	15	168	56.8	0.5	0.37 kW	0.37 kW	0.37 kW	0.37 kW	0.37 kW	0.37 kW
MQPB063B	350	10	0	168	56.9	0.5	0.37 kW	0.37 kW	0.37 kW	0.37 kW	0.37 kW	0.37 kW
MQPB063B	350	10	15	168	56.9	0.5	0.37 kW	0.37 kW	0.37 kW	0.55 kW	0.55 kW	0.55 kW
MQPC063C	450	20	0	219	65.4	0.75	0.37 kW	0.37 kW	0.37 kW	0.55 kW	0.55 kW	0.55 kW
MQPC063C	450	20	15	219	65.4	0.75	0.37 kW	0.37 kW	0.55 kW	0.75 kW	0.75 kW	1.1 kW
MQPD075D	600	50	0	219	87.2	1	0.55 kW	0.55 kW	0.55 kW	0.75 kW	0.75 kW	1.1 kW
MQPD075D	600	50	15	219	87.2	1	0.75 kW	0.75 kW	1.1 kW	2.2 kW	2.2 kW	3 kW
MQPE080E	750	75	0	273	70.0	1	0.55 kW	0.55 kW	0.75 kW	1.1 kW	1.1 kW	1.1 kW
MQPE080E	750	75	15	273	70.0	1	1.1 kW	1.1 kW	1.5 kW	3 kW	3 kW	4 kW
MQPF093F	1000	125	0	323	59.1	1	0.75 kW	0.75 kW	1.1 kW	1.5 kW	1.5 kW	1.5 kW
MQPF093F	1000	125	15	323	59.1	1	1.1 kW	1.5 kW	2.2 kW	4 kW	4 kW	5.5 kW

Customisation

ModQuip offer customisation to your specific requirements and our conveyors are manufactured to accept the following with no modifications. We offer full assembly and site installation including commissioning when required. Due to the versatility, the ModQuip Conveyor Systems can be adapted to suit most applications as a cost effective solutions.
